🧰 3D Printing Reference Guide 📘✨

For Artistic & Collectible 3D Models – Figures, Sculptures, Toys

🎯 1. Choosing a Printing Method

Type FDM (Filament) Resin (SLA/DLP/LCD)

Best for Durable prints, larger models High-detail, smooth surfaces

Material PLA, PETG, ABS Standard Resin, ABS-like Resin

Surface Finish Layered, rougher Smooth, fine details

Cost Lower Higher (resin + cleaning tools)

Setup Easier Needs more safety and post-processing

⚙️ 2. FDM Printer Settings (e.g., PLA Filament)

Layer Height: 0.1 – 0.2 mm (lower = better detail)

Wall Line Count: 2–3

Infill: 10%–25% (Gyroid or Cubic recommended)

Print Speed: 50 mm/s (go slower for small parts)

Temperature:

Nozzle: 190–210°C

Bed: 50–60°C (use glue stick or textured bed for grip)

Supports: Enable for overhangs > 45°

Adhesion: Brim or raft recommended for tall or thin parts

Cooling: 100% fan speed for PLA (except first layer)

✅ Post-Print Tips:

Sand lightly if needed

Prime & paint with acrylics for best results

Use filler primer spray for smoother finishing

🧪 3. Resin Printer Settings

Layer Height: 0.025 – 0.05 mm (ultra detail)

Bottom Exposure: 25–40s (depends on resin/printer)

Normal Exposure: 1.5–2.5s

Lifting Speed: 1.5 – 3 mm/s

Supports: Auto-generate, then manually adjust (medium/light touch)

Resin Type: Use standard or ABS-like resin for durability

✅ Post-Processing:

Wash in isopropyl alcohol (IPA) or cleaning fluid (2–5 mins)

UV cure for 2–5 mins under UV lamp or sunlight

Sand and prime before painting

Always wear gloves and a mask!

🖼️ 4. Model Orientation & Tips

Orientation: Angle parts for fewer supports and better surface finish

Hollowing (Resin only): Optional to save resin – add drain holes!

Splitting Models: For large prints, split into pieces for better quality and less support

Check Grey Preview: Always review the natural (unpainted) color and detail level in slicer before printing — this is how your model will look out of the printer.

💬 Final Notes

🧡 Our models are optimized for ease and beauty, but results depend on print settings.

🎨 Customize freely — sand, prime, paint, and make it yours!

🤝 If you need higher-resolution versions or custom tweaks, feel free to contact us!

Ghostbusters Geistertrupp

0,2 mm Schicht, 2 Wände, 15 % Füllung
