Simple mechanism composed by two gears. In the file you can find several gears with different number of teeth. Thus, you can combine them to obtain different gear ratio.
- Gear files (TOY-002) have in the name the number of teeth. Since the gear pitch is 2mm, the diameter (in mm) is double of the number of teeth.
- TOY-001 and TOY-003 files have in the description the distance (in mm) between the centers of rotation
- A combination is acceptable if the distance between the centre (in mm) is equal to the sum of the number of teeth of the gears.
- Some examples of acceptable combinations:
1. TOY-001_60 / TOY-003_60 / TOY-002_30 / TOY-002_30
2. TOY-001_40 / TOY-003_40 / TOY-002_25 / TOY-002_15
3. TOY-001_30 / TOY-003_30 / TOY-002_10 / TOY-002_20
