The Vortex Rocket Launcher 🚀 Stack, Load, and Blast Off!

Ready for lift-off? This interactive model takes the satisfying spin of a classic "impossible pass-through" vortex toy and supercharges it with a spring-loaded launch!

While most vortex toys feature a moving core inside a static shell, this design flips your expectations entirely: the helical core acts as a fixed launch rail, and the outer rocket shell is propelled spinning into the air! Built for a fast-paced community challenge, this model combines mechanical engineering with highly competitive gameplay. Stack the rails, compress the spring, and see how high you can launch!

✨ Key Innovations & Features

Flipped Vortex Mechanics: A completely reversed helical mechanism where the external rocket shell spins up and off the fixed internal rails.
Infinite Stacking Gameplay: The internal launch rail is built using modular 80mm keyed segments. Stack them as high as you want (and dare!) to compete for maximum launch distance.
Dynamic Color Customization: The modular design allows you to build a varied, visually striking color spectrum on a standard single-extruder printer—no multi-material unit or mid-print pauses required!
Rocket Bumper System: A custom-designed, spring-loaded bumper smoothly transfers mechanical kinetic energy directly into the rocket for a flawless launch.
Easy Printing: Designed for minimal supports and optimized for consumer 3D printers.

🚀 The Launch Sequence (How to Use)

Build the Base & Rail: Assemble the base with its push-to-fit decorations. Stack your 80mm core rail units (they are keyed to ensure perfect orientation) and cap the top.
Prep the Bumper: Weave each end of your compression spring into a Bumper Base, using the built-in notches to lock it securely in place.
Note: Even though the assembled Bumper might look crooked when resting on a flat surface, rest assured that its lifting force capabilities are not hampered. This funny look is due to the spring being attached by a metal friction grip only, which exerts a torque and rotates the base out of flatness.
Load the Rocket: Slide the assembled bumper down the rail, followed by your rocket launch vehicle, until it rests on the extended bumper.
Blast Off: Ensure your airspace is clear, press down firmly on the bumper to compress the spring, and release suddenly! Watch the spring force transfer directly to the vehicle, sending it spinning upward!

⚙️ Print Settings & Hardware Requirements

Required Hardware (The Spring):
To achieve maximum launch velocity, you will need a large outer diameter (OD) compression spring.

Spring specs: 25mm–30mm OD, 1mm wire size, and at least 50mm in free length. (Commonly found on Amazon or AliExpress).

Examples:

Ali Express
Wire Diameter 1mm SUS304 Stainless Steel Large Diameter Compression Spring OD=25mm~40mm Free Length 30mm ~ 150mm
https://www.aliexpress.com/item/3256803522597423.html

Amazon:
uxcell 5Pcs Compression Spring, 25mm OD, 1.6mm Wire Size, 45mm Free Length
https://www.amazon.com/uxcell-Compression-Construction-Extended-Mechanical/dp/B0F9441D4S

Slicer Specs:

Material: Creality Hyper PLA (or any rigid PLA/PETG). For a striking test-flight aesthetic, try printing the rocket in Orange, the modular rail segments in alternating White and Brown, and capping it with a Red tip!
Layer & Infill: 0.20mm layer height with 15% Gyroid infill.
Walls: 4 External Walls (Wall ordering: Outer first, then Inner for dimensional accuracy).
Supports: Minimal! Only required in the stacking sections to preserve hole integrity. (Pro-tip: Set Top Z distance to 0.4mm for clean, easy removal).
Printing Speed: The spiral rail prefers slower printing, like "Silent" mode (50%) to preserve maximum detail and integrity of the spirals. However, be aware that this can add a non-trivial amount of time to your prints.
